What is the blue connector on a fiber optic patch cord called
Home / What is the blue connector on a fiber optic patch cord called
Blue fiber ends typically represent connectors with a PC (Physical Contact) or UPC (Ultra Physical Contact) polish. PC Polish: PC connectors have a slightly curved end-face that ensures the fiber cores come into contact. Among the most commonly used colors for fiber optic connectors are green and blue. Used to connect optical transceivers ↔ transceivers, switches ↔ patch panels, or. What Is a Fiber Optic Patch Cord? A fiber optic patch cord (fiber jumper) is: Typical applications: A patch cord is the "bridge" that connects two fiber devices and lets them talk to each other. They are generally sold in large quantities, rather than custom -made, although quite special models are also. The most commonly used patch cable connectors today include FC, ST, SC, LC, MTRJ, and MPO connector types, as well as newer very small-form-factor (VSFF) CS, SN, and MDC connectors used in high-density, high-speed duplex data center environments.
